VPC Architecture for Multi-VM Applications: Private Network Design
rafftechnologies.com/learn
On this page

Key Takeaways

Keep backend workloads private, plan CIDRs before networks need to connect, separate routing from authorization, and permit only required service relationships. Add segmentation or VPN links only when requirements justify them.

Design your private network across VMs at no extra cost.

  1. 1Pick a Linux imageUbuntu, Debian and more, with your SSH key added.
  2. 2Choose a sizeFrom $4.99 a month. Resize when your app grows.
  3. 3Connect over SSHYour server is up in about 55 seconds.

Ubuntu, Debian and other Linux distributions with full root and SSH access, up and running in about 55 seconds.

VPC architecture is the design of private addressing, routing, security boundaries, and service connectivity that lets multiple cloud resources communicate without exposing every component to the public internet.

For a multi-VM application, a good VPC design keeps the public edge small, moves databases and internal services onto private paths, assigns clear traffic rules between service roles, and leaves enough address space for future VPN or network connections.

Raff Technologies workloads can use VPC private networking so application VMs, databases, workers, Windows servers, and internal services do not need to communicate through public endpoints.

A practical rule is:

Design the VPC around application relationships, not around the number of servers.

VPC architecture: quick answer

A typical multi-tier application can start with this model:

Text
Internet ↓ HTTPS Public application edge ↓ private VPC Application VM(s) ↓ Database / cache / queue / workers Administrators ↓ controlled access path Private resources

The important boundaries are:

BoundaryDefault design
Public user trafficOnly the required application edge
Application-to-databasePrivate VPC path
Cache/queue/worker trafficPrivate VPC path
AdministrationVPN, bastion, or tightly restricted path
Outbound internetOnly where a workload requires it
Cross-network accessExplicit VPN or other controlled connection

A private network should reduce public exposure without turning the entire VPC into one trusted zone.

What is VPC architecture?

A Virtual Private Cloud (VPC) is an isolated network inside a cloud environment where resources can communicate through private addressing and controlled network policy.

VPC architecture determines:

  • which workloads belong to the same private network;
  • which CIDR range the network uses;
  • which services can route to one another;
  • which ports and protocols are permitted;
  • how private resources reach the internet when required;
  • how administrators reach private systems;
  • how the VPC connects to offices, customers, or other networks;
  • how the network is recreated during recovery.

The network should reflect the application graph rather than simply connect every private IP to every other private IP.

VPC design best practices start with workload isolation

The strongest starting point for VPC design is to identify which workloads should be isolated from the public internet.

For most multi-tier applications, these normally include:

  • databases;
  • caches;
  • queues;
  • background workers;
  • internal APIs;
  • monitoring endpoints;
  • administrative interfaces;
  • application backends that sit behind a public edge.

A common architecture is:

Text
Internet ↓ Public web/API edge ↓ private network Application tier ↓ private network Database tier

This gives the application the connectivity it needs without creating a public endpoint for every backend component.

The same principle applies whether the backend is a self-managed VM or a managed service connected through a private path.

Private cloud network design should follow service relationships

A VPC is more useful when policy is expressed in terms of service roles.

SourceDestinationTypical allowed flow
InternetPublic edgeHTTPS or required public protocol
Public edgeApp VMsApplication port only
App VMsDatabaseRequired database port
App VMsCache/queueRequired internal service port
WorkersDatabase/queueRequired worker paths
MonitoringWorkloadsHealth and metrics endpoints
Admin pathServersApproved SSH/RDP/admin traffic

This is better than one broad rule that allows the entire private CIDR to reach everything.

A compromised application VM should not automatically receive unrestricted access to backup systems, unrelated databases, staging environments, or administrative services simply because they share private networking.

Use Cloud Firewall Best Practices for the rule-design layer.

How to isolate backend cloud workloads from the public internet

For a multi-tier application, isolation usually means removing direct public reachability from backend workloads and permitting only approved private sources.

A practical sequence is:

  1. Keep the public website/API endpoint reachable.
  2. Put application backends, databases, workers, caches, and queues on the VPC.
  3. Remove unnecessary public service ports from backend systems.
  4. Permit only the application tier to reach the database port.
  5. Permit only approved workers to reach queue or job-processing endpoints.
  6. Move SSH/RDP administration to a controlled path.
  7. Verify both IPv4 and IPv6 exposure where applicable.
  8. Test that required private paths still work after public exposure is reduced.

Private addressing is only part of the control. Authentication, application authorization, patching, secrets, and firewall policy still matter.

For a practical same-VPC connectivity check on two Ubuntu servers, follow How to Connect Two Raff VMs with a Private VPC Network. Use that setup walkthrough to validate interface addresses, routing, and scoped test traffic before applying production firewall rules.

CIDR planning should happen before the network grows

Private IP ranges are easy to choose early and expensive to change after multiple systems depend on them.

RFC 1918 reserves these IPv4 ranges for private networks:

RangeCIDR
10.0.0.0 – 10.255.255.25510.0.0.0/8
172.16.0.0 – 172.31.255.255172.16.0.0/12
192.168.0.0 – 192.168.255.255192.168.0.0/16

A team might reserve a production range such as:

Text
10.20.0.0/16

and later divide the address plan conceptually:

Text
10.20.10.0/24 application 10.20.20.0/24 database 10.20.30.0/24 workers/queues 10.20.40.0/24 monitoring/admin

This is only an example. The important requirement is to avoid accidental overlap with networks that may later need to connect.

Common overlap problems come from reusing the same range for:

  • production and staging;
  • office networks;
  • VPN client pools;
  • another cloud;
  • MSP customer networks;
  • a second environment that may later require routing.

If two networks that need to communicate use the same addresses, a future VPN or inter-network connection becomes more complicated.

Raff VPC CIDR ranges and overlapping networks

Raff currently documents VPC CIDR sizes from /16 through /28 using RFC 1918 private ranges.

Separate isolated VPCs can use overlapping CIDRs when they remain independent. That can be useful for keeping development, staging, or customer templates consistent.

However, if two networks may later need to connect through a VPN or another routed relationship, plan non-overlapping ranges from the beginning.

Isolation makes overlap possible; future connectivity determines whether overlap is wise.

Routing creates reachability, not authorization

Routing answers:

Where should packets for this destination go?

Security policy answers:

Should this source be allowed to use that path for this service?

Treat them as separate layers:

Text
Route exists ↓ Firewall/security group permits source + port ↓ Service authenticates caller ↓ Application authorizes action

A route to a database subnet should not imply that every VM in the VPC can become a database client.

Likewise, a VPN route to production does not imply that every connected technician should receive administrative rights on every server.

NAT gives private workloads controlled outbound access

A private server may still need internet access for:

  • operating-system updates;
  • package repositories;
  • external APIs;
  • license servers;
  • email providers;
  • monitoring or telemetry.

A NAT or gateway pattern allows that outbound connectivity without requiring direct unsolicited public inbound access to the private VM.

Text
Private workload ↓ outbound VPC gateway / NAT ↓ Internet

Raff currently documents NAT as part of the VPC gateway model together with DNS and DHCP.

NAT is not an authorization system. Review whether each workload needs general outbound internet access and restrict sensitive systems where the architecture requires it.

DNS and DHCP reduce manual network configuration

Multi-VM environments become easier to operate when internal services use predictable names and network settings do not depend on hand-maintained address configuration.

Internal service names such as:

Text
db.production.internal cache.production.internal api.internal

make replacement and environment separation easier than embedding private IPs directly in application configuration.

Raff currently documents managed DNS and DHCP as part of its VPC gateway capabilities.

DNS still becomes a dependency. A healthy database can appear unavailable if the expected private name no longer resolves correctly.

One VPC does not have to mean one flat trust zone

A small application can start with one private network. It does not need complex segmentation simply because larger cloud architectures use many subnets.

Add stronger boundaries when there is a real difference in:

  • trust;
  • ownership;
  • environment;
  • routing;
  • customer separation;
  • security policy;
  • recovery requirements.

Examples include:

  • production vs staging;
  • customer A vs customer B;
  • application vs management;
  • internet-facing vs sensitive data systems.

If the same simple policy works for all systems, extra segmentation may add operational complexity without meaningful benefit.

Development, staging, and production need deliberate separation

Teams sometimes put all environments into one private network because none of them is publicly exposed.

That can still create unnecessary trust.

Separate where appropriate:

  • application credentials;
  • database permissions;
  • CI/CD identities;
  • firewall rules;
  • backup deletion rights;
  • administrative paths.

A compromised development VM should not automatically gain a direct path to the production database.

Use Staging vs Production vs Development Environments for the broader environment model.

Windows and Linux workloads can share the same private architecture

A mixed environment may contain Linux application servers and Windows Server business workloads.

Example:

Text
Public application edge ↓ VPC Linux app VM Windows business VM Database Internal file/service endpoint

Keep RDP and SSH administration separate from normal application traffic where possible.

Raff Windows VM can participate in the same VPC-based network model as Linux Cloud Servers.

For remote administration, use Bastion Host vs VPN vs Public SSH.

Load balancing changes the traffic boundary, not the trust model

When one application VM becomes an unacceptable capacity, deployment, or availability boundary, the architecture may add a traffic-distribution layer in front of several interchangeable application nodes.

Text
Internet ↓ Traffic-distribution layer ↓ Private App VM 1 Private App VM 2 Private App VM 3 ↓ Private database/cache/queue

Before scaling this way, verify:

  • application nodes can serve requests interchangeably;
  • sessions are not unexpectedly tied to one node;
  • durable uploads are not trapped on one VM disk;
  • database connection capacity is adequate;
  • readiness checks represent real service health;
  • remaining nodes have enough capacity after one backend fails.

Raff's managed Load Balancer page is not treated here as a generally available dependency. Confirm current availability before designing around a managed product. The architecture works with any appropriate traffic-distribution implementation.

Use Load Balancing Explained for the detailed model.

Site-to-site VPN extends the VPC to another network

When an office, customer environment, or another approved network needs private access to Raff workloads, a site-to-site VPN can extend the network boundary without exposing every target service publicly.

Text
Office / customer network ↓ site-to-site VPN Raff VPC ↓ Private application / Windows VM / service

Raff's Site-to-Site VPN product page lists separate gateway and per-tunnel charges. A free VPC does not mean the VPN gateway and tunnels are free. Check current pricing and billing units on the live VPN product page before including this connectivity in a deployment budget.

MSPs should plan customer networks for future separation

For MSP and managed-IT workloads, address planning and administrator reachability become customer-isolation decisions.

Avoid architectures where:

  • one flat VPC connects unrelated customers;
  • technicians receive broad routes to all customers;
  • the same administrative credential is reused across customer environments;
  • overlapping networks are later expected to connect to one another;
  • one automation token can modify several unrelated environments.

Prefer customer-scoped credentials, routes, network policy, and explicit offboarding.

Use Secure Remote Access for MSPs for the technician-access model. For the separate question of per-customer private networks and offboarding boundaries, see Private Cloud Networking for MSPs.

Private networking does not automatically encrypt traffic

Network isolation and transport encryption solve different problems.

A private VPC path reduces who can route traffic to a service. It does not inherently mean the application payload is encrypted.

Use TLS or protocol-native encryption when:

  • credentials or sensitive data cross service boundaries;
  • policy requires encryption in transit;
  • traffic crosses different trust zones;
  • end-to-end protection matters to the application.

Private should mean controlled reachability, not implicit trust.

Recovery planning must include the VPC configuration

A restored VM is not a recovered service if its network relationships are missing.

Record:

  • VPC name and CIDR;
  • expected service names;
  • route relationships;
  • security-group/firewall rules;
  • gateway/NAT requirements;
  • VPN relationships;
  • administrative paths;
  • public edge/backend relationships.

After recovery, verify:

  1. Resources are attached to the expected VPC.
  2. Internal DNS names resolve.
  3. Required private ports are reachable.
  4. Unnecessary public ports remain closed.
  5. Applications can reach databases, caches, and queues.
  6. Administrators can reach systems through the intended path.
  7. VPN-connected networks can reach only approved resources.

Use Cloud Snapshots vs Backups for the recovery-copy layer.

How Raff VPC fits a multi-VM application

Raff VPC is Raff's current private-networking foundation.

Current facts used in this guide are:

  • VPC is free;
  • private VPC traffic is unmetered;
  • Raff documents /16 through /28 private CIDR sizes;
  • the VPC gateway currently includes NAT, DNS, and DHCP;
  • stateful security groups provide per-VM network policy;
  • separate VPCs can use overlapping CIDRs when they remain isolated;
  • Site-to-Site VPN is available for network-to-network connectivity.

A practical Raff architecture can evolve gradually:

Text
Stage 1 Public Raff VM → application Stage 2 Public application VM ↓ Raff VPC Private database / worker Stage 3 Traffic-distribution layer ↓ Private application nodes ↓ Raff VPC Private database / cache / workers Stage 4 VPN or another controlled network connection → only when an external private network genuinely needs access

Use Raff Cloud Servers for compute, Windows VM for Windows workloads, Managed Databases when the data layer should be operated separately, Security for Raff's current security surface, and Data Protection for VM recovery planning.

Create a private network for application, database, worker, Windows, and internal service traffic without making every workload public.

VPC architecture checklist

Address planning

  • The CIDR is documented.
  • Future office, VPN, customer, or cloud networks have been considered.
  • Networks that may later connect do not overlap unnecessarily.

Public/private boundary

  • Only required application endpoints are public.
  • Databases, caches, queues, and workers are private by default.
  • SSH/RDP uses a controlled administrative path.

Service policy

  • Application-to-database traffic is source-restricted.
  • Worker and queue paths are explicit.
  • Private network membership does not imply blanket trust.

Operations

  • Internal service names are documented.
  • Required outbound connectivity is understood.
  • Temporary access has an expiry condition.

Recovery

  • VPC attachment is part of the restore process.
  • DNS, firewall rules, routes, and VPN dependencies are tested after recovery.

Frequently asked questions

What is VPC architecture?

VPC architecture is the design of private addressing, routing, network policy, service connectivity, and administrative paths that let cloud workloads communicate through controlled internal networks.

When does a multi-VM application need a VPC?

Use a VPC when several cloud resources need repeatable private communication or when databases, caches, workers, internal APIs, Windows servers, or application backends should not accept direct public traffic.

What are VPC design best practices?

Keep the public edge small, isolate backend services from public access, use non-overlapping address plans where future networks may connect, separate routing from authorization, and allow only required service-to-service traffic.

How should I isolate backend cloud workloads from the public internet?

Put backends on private VPC paths, remove unnecessary public service ports, restrict traffic to approved application or administrator sources, and retain authentication and firewall controls inside the private network.

How should I choose a private CIDR range?

Choose a documented RFC 1918 range with enough room for expected growth and avoid overlap with office networks, VPN pools, customer networks, staging environments, other clouds, and any network you may connect later.

Should every VPC use multiple subnets?

No. A small application can start with one simple private network. Add segmentation only when trust, routing, ownership, customer, environment, or recovery requirements differ.

What is the difference between routing and firewall rules in a VPC?

Routing determines whether a path exists. Firewall or security rules determine whether a source may use that path for a particular service and port.

Does private networking automatically encrypt traffic?

No. Private routing reduces reachability; transport encryption is a separate control. Use TLS or protocol-native encryption when workload or policy requirements call for it.

Can two Raff VPCs use overlapping CIDR ranges?

Raff currently documents isolated VPCs as allowing overlapping private ranges. Avoid overlap when the networks may later need direct routing or VPN connectivity.

What does Raff VPC provide for multi-VM applications?

Raff VPC provides free private networking with unmetered private traffic, documented /16–/28 CIDR sizes, managed NAT/DNS/DHCP gateway functions, and stateful network policy for connected workloads.

Conclusion

VPC architecture should follow the application graph.

Keep public exposure at the edge, move databases and internal services onto private paths, plan address ranges before future network connections force a redesign, and permit service-to-service traffic deliberately rather than treating the whole private network as trusted.

For a small team, the strongest design is usually the simplest one that makes public, private, administrative, and recovery paths obvious. Add segmentation, traffic distribution, or VPN connectivity only when a real isolation, scale, ownership, or connectivity requirement appears.

Sources

Was this article helpful?
Serdar Tekin
Serdar Tekin
Co-Founder & CTO

Co-Founder & CTO at Raff, focused on cloud infrastructure, systems architecture, security, reliability, and production operations.

Design your private network across VMs at no extra cost.

Ubuntu, Debian and other Linux distributions with full root and SSH access, up and running in about 55 seconds.

14-day money-back guarantee

Frequently asked questions

What is VPC architecture?
VPC architecture is the design of private addressing, routing, network policy, service connectivity, and administrative paths that let cloud workloads communicate through controlled internal networks.
When does a multi-VM application need a VPC?
Use a VPC when several cloud resources need repeatable private communication or when databases, caches, workers, internal APIs, Windows servers, or application backends should not accept direct public traffic.
What are VPC design best practices?
Keep the public edge small, isolate backend services from public access, use non-overlapping address plans where future networks may connect, separate routing from authorization, and allow only required service-to-service traffic.
How should I isolate backend cloud workloads from the public internet?
Put backends on private VPC paths, remove unnecessary public service ports, restrict traffic to approved application or administrator sources, and retain authentication and firewall controls inside the private network.
How should I choose a private CIDR range?
Choose a documented RFC 1918 range with enough room for expected growth and avoid overlap with office networks, VPN pools, customer networks, staging environments, other clouds, and any network you may connect later.
Should every VPC use multiple subnets?
No. A small application can start with one simple private network. Add segmentation only when trust, routing, ownership, customer, environment, or recovery requirements differ.
What is the difference between routing and firewall rules in a VPC?
Routing determines whether a path exists. Firewall or security rules determine whether a source may use that path for a particular service and port.
Does private networking automatically encrypt traffic?
No. Private routing reduces reachability; transport encryption is a separate control. Use TLS or protocol-native encryption when workload or policy requirements call for it.
Can two Raff VPCs use overlapping CIDR ranges?
Raff currently documents isolated VPCs as allowing overlapping private ranges. Avoid overlap when the networks may later need direct routing or VPN connectivity.
What does Raff VPC provide for multi-VM applications?
Raff VPC provides free private networking with unmetered private traffic, documented /16–/28 CIDR sizes, managed NAT/DNS/DHCP gateway functions, and stateful network policy for connected workloads.
