Generate SSH Keys on Ubuntu 24.04: Ed25519 Setup Guide
rafftechnologies.com/learn
On this page

Prerequisites

  • A Raff Linux VM running Ubuntu 24.04, current SSH or browser-console access, and a local Linux, macOS, or Windows computer with OpenSSH

Create a Raff server that takes your new SSH key from first boot.

Tested on 2 vCPU and 2 GB RAM: $12.99 a month

  1. 1Pick a Linux imageUbuntu, Debian and more, with your SSH key added.
  2. 2Choose a sizeFrom $4.99 a month. Resize when your app grows.
  3. 3Connect over SSHYour server is up in about 55 seconds.

Ubuntu, Debian and other Linux distributions with full root and SSH access, up and running in about 55 seconds.

SSH key authentication uses a public and private key pair instead of relying on a reusable server password. The private key stays on your local computer, while the public key is added to the Ubuntu account you want to access.

In this tutorial, you will generate an Ed25519 SSH key, copy it to Ubuntu 24.04, verify the correct identity is used, configure ssh-agent, disable password authentication safely, and rotate or revoke keys later.

This workflow is written for a Raff Linux VM running Ubuntu 24.04, but the OpenSSH key-management steps also apply to standard Ubuntu 24.04 servers. Keep a working SSH session or browser-console recovery path open before changing authentication settings.

Step 1 — Check for Existing SSH Keys

Run this on your local computer:

Bash
ls -la ~/.ssh

Common key files include:

Text
id_ed25519 id_ed25519.pub id_rsa id_rsa.pub

Do not overwrite an existing private key unless you intentionally want to replace it. You can create a separate key for Raff servers, a specific environment, or a specific team member.

Step 2 — Generate an Ed25519 Key Pair

Generate a new key on your local computer:

Bash
ssh-keygen -t ed25519 -a 100 -C "raff-ubuntu-access"

When prompted for a file name, press Enter for the default path or choose a descriptive name such as:

Text
~/.ssh/raff_ed25519

Set a passphrase for interactive administrator keys. The passphrase protects the private key if the local device or key file is copied.

The two generated files have different roles:

  • id_ed25519 or your custom filename is the private key. Do not upload or share it.
  • The matching .pub file is the public key. This is the file copied to servers.

Ed25519 is the preferred default for modern OpenSSH systems. Use RSA only when a legacy system or policy specifically requires it.

Step 3 — Inspect the Public Key and Fingerprint

Display the public key:

Bash
cat ~/.ssh/id_ed25519.pub

For a custom filename:

Bash
cat ~/.ssh/raff_ed25519.pub

Display its fingerprint:

Bash
ssh-keygen -lf ~/.ssh/id_ed25519.pub

Fingerprints help identify keys during audits and rotation without comparing the entire public-key string.

Step 4 — Copy the Public Key to Ubuntu

The simplest method is ssh-copy-id:

Bash
ssh-copy-id your_user@your_server_ip

For a custom public key:

Bash
ssh-copy-id -i ~/.ssh/raff_ed25519.pub your_user@your_server_ip

The command authenticates using the server's current access method and appends the public key to the user's ~/.ssh/authorized_keys file.

When ssh-copy-id is unavailable, use this fallback from your local computer:

Bash
cat ~/.ssh/id_ed25519.pub | \ ssh your_user@your_server_ip \ 'umask 077; mkdir -p ~/.ssh; cat >> ~/.ssh/authorized_keys'

On the server, verify ownership and permissions:

Bash
chmod 700 ~/.ssh chmod 600 ~/.ssh/authorized_keys chown -R "$USER":"$USER" ~/.ssh

Step 5 — Verify Key Authentication in a New Session

Keep the original SSH session open and test a separate connection:

Bash
ssh your_user@your_server_ip

When using a custom key, specify it explicitly:

Bash
ssh -i ~/.ssh/raff_ed25519 your_user@your_server_ip

Use verbose output when troubleshooting:

Bash
ssh -vv -i ~/.ssh/raff_ed25519 your_user@your_server_ip

Look for output showing that the client offered the intended public key and that authentication succeeded. Exact wording varies by OpenSSH version.

Confirm the server stored the expected public key:

Bash
nl -ba ~/.ssh/authorized_keys

Do not disable passwords until a new key-based session succeeds.

Step 6 — Load the Key into ssh-agent

Start an agent in the current local shell when one is not already available:

Bash
eval "$(ssh-agent -s)"

Add the key:

Bash
ssh-add ~/.ssh/id_ed25519

Or add the custom key:

Bash
ssh-add ~/.ssh/raff_ed25519

List loaded identities:

Bash
ssh-add -l

The agent keeps the decrypted key available for the session so you do not have to re-enter its passphrase for every connection. Desktop operating systems may provide their own agent or secure key integration.

Step 7 — Disable Password Authentication Safely

Ubuntu's OpenSSH package includes /etc/ssh/sshd_config.d/*.conf near the start of the main configuration. For most sshd_config keywords, OpenSSH uses the first value it obtains, so a later file such as 99-something.conf does not reliably override an earlier drop-in.

Inspect the existing authentication settings first:

Bash
sudo grep -RniE \ '^[[:space:]]*(PubkeyAuthentication|PasswordAuthentication|KbdInteractiveAuthentication|PermitRootLogin)[[:space:]]' \ /etc/ssh/sshd_config /etc/ssh/sshd_config.d 2>/dev/null

Create an early drop-in for the key-only policy:

Bash
sudo nano /etc/ssh/sshd_config.d/00-raff-key-auth.conf

Add:

Text
PubkeyAuthentication yes PasswordAuthentication no KbdInteractiveAuthentication no

Validate the complete configuration:

Bash
sudo sshd -t

Check the effective values rather than assuming the drop-in won:

Bash
sudo sshd -T | grep -E '^(pubkeyauthentication|passwordauthentication|kbdinteractiveauthentication) '

The expected values are:

Text
pubkeyauthentication yes passwordauthentication no kbdinteractiveauthentication no

If an effective value is still different, inspect the earlier matching directive and correct the file that wins. Do not keep adding higher-numbered drop-ins and assume the last filename overrides earlier settings.

Reload the service only after sshd -t succeeds:

Bash
sudo systemctl reload ssh

Keep the existing session open and test a new key-based connection. Then explicitly test that password-only authentication is rejected:

Bash
ssh -o PreferredAuthentications=password \ -o PubkeyAuthentication=no \ your_user@your_server_ip

The connection should be denied rather than presenting a usable password login.

Verify: a new key-based session succeeds, sshd -T reports password and keyboard-interactive authentication disabled, and a password-only test is rejected.

Step 8 — Disable Root SSH Login After Sudo Access Works

First confirm the regular account can run sudo:

Bash
sudo whoami

The result should be root.

Add the following to the same early drop-in file:

Bash
sudo nano /etc/ssh/sshd_config.d/00-raff-key-auth.conf

Add:

Text
PermitRootLogin no

Validate and reload again:

Bash
sudo sshd -t sudo systemctl reload ssh

Test the normal administrative account in another terminal before closing the current session. Root-login restrictions and password restrictions should be applied only after the replacement access path is proven.

Step 9 — Create a Local SSH Config Entry

Create or edit the config file on your local computer:

Bash
nano ~/.ssh/config

Add:

Text
Host raff-production HostName your_server_ip User your_user IdentityFile ~/.ssh/raff_ed25519 IdentitiesOnly yes ServerAliveInterval 60

Protect the file:

Bash
chmod 600 ~/.ssh/config

Connect using the alias:

Bash
ssh raff-production

IdentitiesOnly yes is useful when your agent contains several keys because it tells the client to use the configured identity rather than offering many unrelated keys.

Step 10 — Add a Second Administrator Without Sharing Keys

Each person should generate and control their own private key. Add only their public key to the appropriate server account.

For a separate Linux account:

Bash
sudo adduser secondadmin sudo usermod -aG sudo secondadmin sudo install -d -m 700 -o secondadmin -g secondadmin /home/secondadmin/.ssh

Add the person's public key to:

Text
/home/secondadmin/.ssh/authorized_keys

Then set ownership and permissions:

Bash
sudo chown secondadmin:secondadmin /home/secondadmin/.ssh/authorized_keys sudo chmod 600 /home/secondadmin/.ssh/authorized_keys

Separate accounts and keys make access review, revocation, and log attribution clearer.

Step 11 — Rotate or Revoke an SSH Key

List authorized keys with line numbers:

Bash
nl -ba ~/.ssh/authorized_keys

Before removing an old key, add and test the replacement key in a separate session. Then edit the file:

Bash
nano ~/.ssh/authorized_keys

Delete only the line belonging to the key being revoked.

You can identify a public key's fingerprint by saving the line to a temporary file or by checking the original .pub file:

Bash
ssh-keygen -lf ~/.ssh/raff_ed25519.pub

If a private key is lost or suspected to be copied, remove its public key from every server that trusts it. Changing the key's local passphrase does not revoke a copy that may already exist elsewhere.

Step 12 — Troubleshoot Common SSH Key Problems

The server still asks for a password

Check the local key being offered:

Bash
ssh -vv -i ~/.ssh/raff_ed25519 your_user@your_server_ip

Check server-side permissions:

Bash
namei -l ~/.ssh/authorized_keys

The home directory must not be writable by unrelated users, .ssh should normally be 700, and authorized_keys should normally be 600.

Too many authentication failures

Specify the key and prevent the client from offering unrelated agent identities:

Bash
ssh -o IdentitiesOnly=yes \ -i ~/.ssh/raff_ed25519 \ your_user@your_server_ip

OpenSSH ignores a configuration change

Validate syntax and inspect effective settings:

Bash
sudo sshd -t sudo sshd -T | grep -E '^(permitrootlogin|pubkeyauthentication|passwordauthentication|kbdinteractiveauthentication) '

Review all drop-ins:

Bash
sudo grep -RniE '^(PermitRootLogin|PubkeyAuthentication|PasswordAuthentication|KbdInteractiveAuthentication)' \ /etc/ssh/sshd_config /etc/ssh/sshd_config.d

You lose normal SSH access

Use the Raff browser console to inspect SSH configuration, restore an authorized public key, or correct firewall rules. Keep a tested recovery method available before making remote-access changes.

Conclusion

You now have an Ed25519 SSH key, verified public-key authentication, optional agent and client configuration, disabled password access, and a safe process for adding, rotating, and revoking administrator keys.

Continue with How to Set Up UFW Firewall on Ubuntu 24.04 and How to Harden an Ubuntu 24.04 Server to complete the initial security baseline.

For interactive administrator logins that need a second factor, continue with SSH key plus TOTP MFA on Ubuntu 24.04 after confirming key access and a separate recovery session. Each administrator should retain an individual key rather than share credentials.

SSH key access is included with Raff Linux VMs. Check the Raff pricing page for the current VM sizes and billing terms instead of relying on a hard-coded tutorial price.

Create a Raff Ubuntu VM, add your Ed25519 public key during setup, and keep a recovery path available before changing SSH authentication.

Tested on 2 vCPU and 2 GB RAM: $12.99 a month · 14-day money-back guarantee

Deploy Your Server
Was this article helpful?
Serdar Tekin
Serdar Tekin
Co-Founder & CTO

Co-Founder & CTO at Raff, focused on cloud infrastructure, systems architecture, security, reliability, and production operations.

Create a Raff server that takes your new SSH key from first boot.

Tested on 2 vCPU and 2 GB RAM: $12.99 a month

Ubuntu, Debian and other Linux distributions with full root and SSH access, up and running in about 55 seconds.

14-day money-back guarantee

Frequently asked questions

Where are SSH keys stored on Ubuntu?
A user's authorized public keys are normally stored in ~/.ssh/authorized_keys. Private keys should remain on the local client and are commonly stored under the client's ~/.ssh directory.
Should I use Ed25519 or RSA for SSH?
Use Ed25519 for modern OpenSSH systems. Use RSA only when a legacy system or organizational policy requires compatibility that Ed25519 cannot provide.
Can I use the same SSH key on several servers?
Technically yes, but separate keys by person, device, environment, or automation role when practical. Smaller trust scopes make rotation and incident response easier.
Can I disable SSH passwords immediately?
Only after a public key has been installed and tested in a separate session. Keep the original connection open until the key-only login and sudo access are confirmed.
What should I do if an SSH private key is lost?
Remove the matching public key from every authorized_keys file and provisioning system that trusts it, then create and deploy a replacement key.
