How to Set Up SSH MFA on Ubuntu 24.04

In this tutorial, you will set up SSH multi-factor authentication on Ubuntu 24.04 so an interactive administrator must present both a valid SSH key and a time-based one-time password (TOTP) code. The procedure uses Ubuntu's libpam-google-authenticator package, OpenSSH keyboard-interactive authentication, explicit rollback files, and a second-session test before the original SSH connection is closed.

SSH MFA is an authentication design that requires more than one independent factor before a login succeeds. In this setup, the SSH private key is the first factor and a rotating TOTP code from an authenticator app is the second factor.

Raff Technologies supports 3,000+ customers and 15,000+ VMs. A Raff Linux VM provides the Ubuntu environment, root-level SSH configuration, firewall controls, snapshots, backups, and web console access needed to operate administrative access safely.

The original SSH MFA workflow was tested on a Raff Ubuntu 24.04 VM with 1 vCPU and 2 GB RAM. This revision corrects the PAM flow for SSH key + TOTP specifically and refreshes the configuration against Ubuntu 24.04's current OpenSSH 9.6p1 and libpam-google-authenticator documentation. Ubuntu 24.04 currently ships libpam-google-authenticator version 20191231-2build1.

Prerequisites:

• A Raff Ubuntu 24.04 VM
• A non-root administrator account with sudo privileges
• Working SSH key authentication for every interactive administrator who will use this server
• A TOTP-compatible authenticator app
• Access to the Raff web console or another recovery path in case SSH configuration must be rolled back

Scope: This tutorial configures SSH key + TOTP. It deliberately disables SSH password authentication and removes the normal PAM password check from the SSH authentication stack. If automation or service accounts depend on unattended SSH, review those accounts before applying MFA globally.

Step 1 — Verify SSH key access and create a safe rollback point

Keep your current SSH session open for the entire change. Open a second terminal and confirm that your SSH key works before modifying PAM or OpenSSH:

ssh your-user@your-server-ip

On the server, confirm the current user and active SSH service:

whoami
systemctl is-active ssh

Back up the two configuration files that will change:

sudo cp --preserve=all /etc/pam.d/sshd /etc/pam.d/sshd.pre-mfa
sudo cp --preserve=all /etc/ssh/sshd_config /etc/ssh/sshd_config.pre-mfa

Create a backup directory for any SSH drop-ins you add during this tutorial:

sudo install -d -m 700 /root/ssh-mfa-backup
sudo cp -a /etc/ssh/sshd_config.d /root/ssh-mfa-backup/sshd_config.d

Verify the backups exist:

sudo ls -l /etc/pam.d/sshd.pre-mfa /etc/ssh/sshd_config.pre-mfa
sudo test -d /root/ssh-mfa-backup/sshd_config.d && echo "SSH drop-in backup exists"

Verification is complete when SSH key login works in a second session and the PAM, main SSH configuration, and drop-in directory have backup copies.

Step 2 — Install the Google Authenticator PAM module

Update APT metadata and install the Ubuntu 24.04 package:

sudo apt update
sudo apt install -y libpam-google-authenticator

Check the installed package version:

dpkg-query -W -f='${Package} ${Version}\n' libpam-google-authenticator

Ubuntu 24.04 currently provides 20191231-2build1. The package includes the google-authenticator enrollment command and pam_google_authenticator.so, which validates TOTP codes during PAM authentication.

Verify the PAM module exists:

test -f /usr/lib/x86_64-linux-gnu/security/pam_google_authenticator.so \
  || find /usr/lib -name pam_google_authenticator.so -print

For package details, see the Ubuntu 24.04 package record.

Verification is complete when the package is installed and pam_google_authenticator.so is present on the server.

Step 3 — Enroll the SSH administrator in TOTP

Run the enrollment command as the same non-root user who will log in over SSH:

google-authenticator -t -d -r 3 -R 30 -w 3 -e 5

The options configure:

• TOTP rather than counter-based HOTP
• Reuse protection for a code that has already authenticated
• A maximum of 3 attempts every 30 seconds
• The normal three-code time window: previous, current, and next 30-second step
• Five emergency codes

Scan the QR code with your authenticator app and verify the first code when prompted. Store the emergency codes somewhere protected and separate from the VM.

The command writes the user's secret and settings to:

~/.google_authenticator

Set the permissions explicitly to the mode expected by the Ubuntu PAM module:

chmod 600 ~/.google_authenticator

Verify ownership and permissions without displaying the secret:

stat -c '%U %G %a %n' ~/.google_authenticator

Expected state resembles:

your-user your-user 600 /home/your-user/.google_authenticator

Check server time synchronization because TOTP depends on reasonably accurate time:

timedatectl show -p NTPSynchronized --value

Expected output:

yes

The Ubuntu PAM module requires a per-user secret file unless the weaker nullok option is used. This tutorial does not use nullok; enroll every interactive SSH administrator before enforcing MFA. See the Ubuntu PAM module documentation for the secret-file and permission rules.

Verification is complete when the authenticator app generates matching TOTP codes, ~/.google_authenticator is owned by the SSH user with mode 600, and the server clock is synchronized.

Step 4 — Enroll every other interactive SSH administrator before enforcement

If this server has more than one human administrator, each account must run its own enrollment before you enable the global MFA requirement:

google-authenticator -t -d -r 3 -R 30 -w 3 -e 5
chmod 600 ~/.google_authenticator

For each expected administrator, verify the secret file exists without reading it:

sudo stat -c '%U %a %n' /home/USERNAME/.google_authenticator

Do not share one TOTP secret between multiple people. Each administrator should have an independent secret and recovery codes.

If a non-human service account uses SSH keys for automation, do not continue with a global MFA policy until you have designed and tested an explicit exception or a different access path for that service account.

Verification is complete when every human SSH administrator who must retain access has an individual .google_authenticator file and any unattended SSH accounts have been identified before enforcement.

Step 5 — Configure PAM for SSH key plus TOTP

Ubuntu's default /etc/pam.d/sshd includes the common password-authentication stack through:

@include common-auth

For SSH key + TOTP, leaving that line active can cause PAM keyboard-interactive authentication to request a Unix password in addition to the TOTP code. This tutorial removes that password check from the SSH auth stack and uses pam_google_authenticator.so as the keyboard-interactive factor.

Edit the SSH PAM file:

sudoedit /etc/pam.d/sshd

Near the top, comment the normal password-auth line and add the Google Authenticator module:

# Standard Un*x authentication.
# @include common-auth
auth required pam_google_authenticator.so

Leave the existing account, session, and password-update sections unchanged.

Verify the relevant lines:

sudo grep -nE 'common-auth|pam_google_authenticator' /etc/pam.d/sshd

Expected state:

# @include common-auth
auth required pam_google_authenticator.so

Do not add nullok. That option permits accounts without a secret file to bypass the TOTP module during rollout, which conflicts with the mandatory-MFA outcome of this tutorial.

Verification is complete when common-auth is commented only in /etc/pam.d/sshd and pam_google_authenticator.so is an active required auth module.

Step 6 — Configure OpenSSH to require the key and PAM TOTP challenge

Ubuntu 24.04's OpenSSH configuration includes /etc/ssh/sshd_config.d/*.conf before the main settings, and OpenSSH uses the first value it obtains for most keywords. Create an early drop-in so the MFA settings win over later defaults and cloud-init files:

sudo tee /etc/ssh/sshd_config.d/00-raff-ssh-mfa.conf > /dev/null <<'EOF'
PubkeyAuthentication yes
PasswordAuthentication no
KbdInteractiveAuthentication yes
UsePAM yes
AuthenticationMethods publickey,keyboard-interactive:pam
PermitRootLogin no
EOF

This requires both methods in sequence:

publickey → keyboard-interactive via PAM

keyboard-interactive:pam explicitly selects PAM as the second authentication device. PasswordAuthentication no prevents OpenSSH's separate password method from becoming an alternate login path.

ChallengeResponseAuthentication is a deprecated alias for KbdInteractiveAuthentication; use the modern directive name on Ubuntu 24.04. The current Ubuntu sshd_config documentation also confirms that AuthenticationMethods can require multiple comma-separated methods in sequence. See the Ubuntu 24.04 OpenSSH configuration manual.

Validate syntax before touching the running daemon:

sudo sshd -t

No output means the syntax is valid.

Inspect the effective authentication settings:

sudo sshd -T | grep -E '^(pubkeyauthentication|passwordauthentication|kbdinteractiveauthentication|usepam|authenticationmethods|permitrootlogin) '

Expected values include:

pubkeyauthentication yes
passwordauthentication no
kbdinteractiveauthentication yes
usepam yes
authenticationmethods publickey,keyboard-interactive:pam
permitrootlogin no

Verification is complete when sshd -t returns no error and sshd -T shows the intended key-plus-PAM authentication policy.

Step 7 — Reload SSH without closing the recovery session

Keep the original SSH session open. Reload OpenSSH rather than stopping it:

sudo systemctl reload ssh

Verify the service remains active:

systemctl is-active ssh

Expected output:

active

Re-run the configuration checks after reload:

sudo sshd -t
sudo sshd -T | grep -E '^(passwordauthentication|kbdinteractiveauthentication|authenticationmethods) '

If any check fails, restore the backups from Step 1 from the still-open recovery session before attempting another login.

Verification is complete when SSH remains active after reload and the effective settings still require publickey,keyboard-interactive:pam.

Step 8 — Test SSH key plus TOTP in a new session

From a separate terminal, connect with verbose authentication output:

ssh -v your-user@your-server-ip

The expected flow is:

1. The SSH public key is accepted.
2. OpenSSH reports partial authentication success or moves to keyboard-interactive.
3. PAM prompts for a verification code.
4. You enter the current TOTP code.
5. The shell opens without a Unix password prompt.

After login, confirm the remote identity:

whoami
hostname

In the original recovery session, inspect recent SSH authentication events:

sudo journalctl -u ssh --since '-10 minutes' --no-pager | tail -n 80

On Ubuntu systems that log SSH authentication to /var/log/auth.log, you can also inspect:

sudo tail -n 80 /var/log/auth.log

A successful test must require both the key and a valid TOTP code. A key-only login should fail, and a TOTP code without the matching private key must not be enough to authenticate.

Verification is complete when a new SSH session succeeds only after the SSH key and TOTP challenge both pass, with no Unix password prompt.

Step 9 — Verify recovery before closing the original session

Test one emergency code from a controlled second session only if your recovery policy permits consuming one. Each emergency code is single-use.

At minimum, verify that the protected recovery material exists and that you can reach an out-of-band recovery path such as the Raff web console before closing the original connection.

Keep these rollback commands available in the original session:

sudo cp --preserve=all /etc/pam.d/sshd.pre-mfa /etc/pam.d/sshd
sudo cp --preserve=all /etc/ssh/sshd_config.pre-mfa /etc/ssh/sshd_config
sudo rm -f /etc/ssh/sshd_config.d/00-raff-ssh-mfa.conf
sudo rm -rf /etc/ssh/sshd_config.d
sudo cp -a /root/ssh-mfa-backup/sshd_config.d /etc/ssh/sshd_config.d
sudo sshd -t
sudo systemctl reload ssh

Use this rollback only from an already authenticated console or SSH session. Do not close the working session until a separate MFA login has succeeded.

Verification is complete when a separate MFA login works and you have confirmed a usable recovery path before ending the original session.

Step 10 — Verify SSH MFA end to end

Run the final server checks:

sudo sshd -t
sudo sshd -T | grep -E '^(pubkeyauthentication|passwordauthentication|kbdinteractiveauthentication|usepam|authenticationmethods|permitrootlogin) '
stat -c '%U %a %n' ~/.google_authenticator
systemctl is-active ssh

From a new client session, verify the full login path again:

ssh your-user@your-server-ip

End-to-end verification is complete when all of the following are true:

• SSH key authentication succeeds as the first factor
• A TOTP prompt is required as the second factor
• No Unix password prompt appears
• PasswordAuthentication is disabled
• Root SSH login is disabled
• pam_google_authenticator.so is required in /etc/pam.d/sshd
• ~/.google_authenticator is owned by the user with mode 600
• A second MFA-protected SSH session opens successfully
• The original recovery session is not closed until the second session works

Troubleshooting

SSH asks for a Unix password after the TOTP code

Check /etc/pam.d/sshd:

sudo grep -nE 'common-auth|pam_google_authenticator' /etc/pam.d/sshd

For this key-plus-TOTP design, @include common-auth should be commented and auth required pam_google_authenticator.so should be active.

The SSH key works but no TOTP prompt appears

Inspect the effective OpenSSH settings:

sudo sshd -T | grep -E '^(kbdinteractiveauthentication|usepam|authenticationmethods) '

Expected values are:

kbdinteractiveauthentication yes
usepam yes
authenticationmethods publickey,keyboard-interactive:pam

If a different drop-in wins, inspect the files in lexical order:

sudo ls -1 /etc/ssh/sshd_config.d/
sudo grep -RniE 'KbdInteractiveAuthentication|AuthenticationMethods|PasswordAuthentication' /etc/ssh/sshd_config /etc/ssh/sshd_config.d/

TOTP codes are rejected

Check time synchronization and secret-file permissions:

timedatectl status
stat -c '%U %G %a %n' ~/.google_authenticator

The server clock should be synchronized and the file should belong to the login user with mode 600.

SSH reports Permission denied after the PAM change

Do not close the original session. Check syntax and logs:

sudo sshd -t
sudo journalctl -u ssh --since '-10 minutes' --no-pager | tail -n 100
sudo tail -n 100 /var/log/auth.log 2>/dev/null || true

If necessary, use the rollback block from Step 9 and reload SSH.

An automation account can no longer connect

The global AuthenticationMethods publickey,keyboard-interactive:pam policy requires TOTP for every SSH login. Restore the previous configuration first if production automation is affected, then design a narrow Match-based exception and test it independently before reenabling the global policy.

A user lost the authenticator device

Use a stored single-use emergency code or an out-of-band console to regain access. After recovery, run google-authenticator again for that user to rotate the TOTP secret and store the new emergency codes securely.

Cleanup and rollback

If you decide to remove SSH MFA, do it from an already authenticated SSH or console session and keep that session open while testing the rollback.

Restore the PAM configuration:

sudo cp --preserve=all /etc/pam.d/sshd.pre-mfa /etc/pam.d/sshd

Restore the original SSH drop-ins and main file:

sudo cp --preserve=all /etc/ssh/sshd_config.pre-mfa /etc/ssh/sshd_config
sudo rm -rf /etc/ssh/sshd_config.d
sudo cp -a /root/ssh-mfa-backup/sshd_config.d /etc/ssh/sshd_config.d

Validate and reload:

sudo sshd -t
sudo systemctl reload ssh

Open a second terminal and verify the intended pre-MFA login path before deleting any .google_authenticator file or backup.

Verification is complete when the restored SSH policy has been tested successfully from a new session.

Conclusion and next steps

You now have SSH key + TOTP authentication on Ubuntu 24.04: OpenSSH requires the public key first, PAM supplies the TOTP challenge second, password authentication is disabled, and the original session remains available until the new MFA path has been verified.

For the surrounding access controls, continue with Set Up SSH Keys on Ubuntu 24.04, Set Up UFW Firewall on Ubuntu 24.04, and Install fail2ban on Ubuntu 24.04. Raff Security provides the infrastructure-level controls that complement host-level SSH hardening.
