Install Prometheus and Grafana on Ubuntu 24.04

To install Prometheus on Ubuntu 24.04 with Grafana, run Prometheus and Node Exporter as dedicated systemd services, keep their web interfaces private, install Grafana from its official stable APT repository, and verify that Grafana can query live host metrics from Prometheus.

This tutorial uses a Raff Technologies Linux VM as the reference Ubuntu server. The single-VM design intentionally binds Prometheus, Node Exporter, and Grafana to 127.0.0.1, so ports 9090, 9100, and 3000 are not exposed directly to the public internet. Administrators reach Grafana through an SSH tunnel.

The previous version of this tutorial used Prometheus 3.5.5 LTS. That LTS line reached end of support on July 31, 2026. As of September 7, 2026, the supported Prometheus LTS line is 3.13, and this tutorial pins Prometheus 3.13.2 LTS. Node Exporter remains at 1.12.1. Grafana is installed from the official stable APT repository instead of being pinned to a manual package, so normal package maintenance can deliver stable Grafana updates.

The original monitoring workflow was tested on a Raff Ubuntu 24.04 VM with 2 vCPU and 4 GB RAM. Prometheus 3.13.2, Node Exporter 1.12.1, and the current Grafana repository instructions were documentation-reviewed for this refresh; no new full machine retest is claimed.

Prerequisites:

• An Ubuntu 24.04 Linux VM on Raff
• SSH access with a non-root sudo user
• SSH key authentication recommended
• Enough disk capacity for your chosen Prometheus retention period
• A recovery path before changing firewall rules

Step 1 — Prepare Ubuntu 24.04

Update packages and install the utilities used in this tutorial:

sudo apt update
sudo apt upgrade -y
sudo apt install -y curl wget tar gnupg ca-certificates ufw jq

If the upgrade requires a reboot, schedule it before continuing:

test -f /var/run/reboot-required && cat /var/run/reboot-required

Check the operating system and current resources:

lsb_release -ds
nproc
free -h
df -h /

A 2 vCPU / 4 GB RAM VM is a practical starting point for this small single-node tutorial, but Prometheus storage and memory needs depend on scrape frequency, retention, target count, and metric cardinality.

Verify: Ubuntu should report 24.04 LTS and the VM should have enough CPU, memory, and free disk for the monitoring workload you intend to retain.

Step 2 — Create dedicated service users and Prometheus directories

Create non-login accounts for Prometheus and Node Exporter:

sudo useradd --system --no-create-home --shell /usr/sbin/nologin prometheus 2>/dev/null || true
sudo useradd --system --no-create-home --shell /usr/sbin/nologin node_exporter 2>/dev/null || true

Create Prometheus configuration and data directories:

sudo install -d -o prometheus -g prometheus /etc/prometheus
sudo install -d -o prometheus -g prometheus /var/lib/prometheus

Check the accounts and ownership:

getent passwd prometheus
getent passwd node_exporter
ls -ld /etc/prometheus /var/lib/prometheus

Verify: both service accounts should exist and the Prometheus directories should be owned by prometheus.

Step 3 — Install Prometheus 3.13.2 LTS and verify the download

Prometheus 3.13 is the current supported LTS line for this tutorial. Download the Linux AMD64 archive:

cd /tmp
PROMETHEUS_VERSION="3.13.2"
PROMETHEUS_ARCHIVE="prometheus-${PROMETHEUS_VERSION}.linux-amd64.tar.gz"

curl -fLO "https://github.com/prometheus/prometheus/releases/download/v${PROMETHEUS_VERSION}/${PROMETHEUS_ARCHIVE}"

Verify the SHA-256 checksum published by Prometheus:

echo "0e8c4d46101bd025ea8265e377d2caabc57f488fc1be1c367f37db69ea41be6f  ${PROMETHEUS_ARCHIVE}" | sha256sum -c -

Expected output:

prometheus-3.13.2.linux-amd64.tar.gz: OK

Extract and install the binaries:

tar -xzf "$PROMETHEUS_ARCHIVE"
cd "prometheus-${PROMETHEUS_VERSION}.linux-amd64"

sudo install -m 0755 prometheus promtool /usr/local/bin/

Verify both binaries:

prometheus --version | head -n 1
promtool --version | head -n 1

The output should report version 3.13.2.

Verify: the checksum should pass and both installed binaries should report Prometheus 3.13.2.

Step 4 — Configure Prometheus to scrape itself and Node Exporter

Create /etc/prometheus/prometheus.yml:

sudo tee /etc/prometheus/prometheus.yml > /dev/null <<'EOF'
global:
  scrape_interval: 15s
  evaluation_interval: 15s

scrape_configs:
  - job_name: "prometheus"
    static_configs:
      - targets: ["127.0.0.1:9090"]

  - job_name: "node_exporter"
    static_configs:
      - targets: ["127.0.0.1:9100"]
EOF

Set ownership and validate the configuration:

sudo chown prometheus:prometheus /etc/prometheus/prometheus.yml
promtool check config /etc/prometheus/prometheus.yml

Verify: promtool should report a successful configuration check and both localhost scrape targets should be present.

Step 5 — Run Prometheus under systemd on localhost only

Create the service unit:

sudo tee /etc/systemd/system/prometheus.service > /dev/null <<'EOF'
[Unit]
Description=Prometheus Monitoring
Wants=network-online.target
After=network-online.target

[Service]
User=prometheus
Group=prometheus
Type=simple
ExecStart=/usr/local/bin/prometheus \
  --config.file=/etc/prometheus/prometheus.yml \
  --storage.tsdb.path=/var/lib/prometheus \
  --storage.tsdb.retention.time=15d \
  --web.listen-address=127.0.0.1:9090
Restart=on-failure
RestartSec=5

[Install]
WantedBy=multi-user.target
EOF

The explicit 15d retention value makes the tutorial's starting policy visible instead of leaving it implicit. Change it only after checking disk growth and deciding how much incident history you need.

Start Prometheus:

sudo systemctl daemon-reload
sudo systemctl enable --now prometheus

Check the service, readiness endpoint, and bind address:

systemctl is-active prometheus
curl -fsS http://127.0.0.1:9090/-/ready
ss -lntp | grep ':9090'

Expected listener:

127.0.0.1:9090

Verify: Prometheus should be active and ready, with port 9090 bound only to localhost.

Step 6 — Install Node Exporter 1.12.1 and verify its checksum

Download Node Exporter:

cd /tmp
NODE_EXPORTER_VERSION="1.12.1"
NODE_EXPORTER_ARCHIVE="node_exporter-${NODE_EXPORTER_VERSION}.linux-amd64.tar.gz"

curl -fLO "https://github.com/prometheus/node_exporter/releases/download/v${NODE_EXPORTER_VERSION}/${NODE_EXPORTER_ARCHIVE}"

Verify the official Linux AMD64 checksum:

echo "b51d8a76aa2a9156a55d501aca6276fae09e262259a5e4e831d2c2222f084e63  ${NODE_EXPORTER_ARCHIVE}" | sha256sum -c -

Extract and install the binary:

tar -xzf "$NODE_EXPORTER_ARCHIVE"
sudo install -m 0755 \
  "node_exporter-${NODE_EXPORTER_VERSION}.linux-amd64/node_exporter" \
  /usr/local/bin/node_exporter

Verify the version:

node_exporter --version | head -n 1

Verify: the checksum should pass and Node Exporter should report version 1.12.1.

Step 7 — Run Node Exporter under systemd on localhost only

Create the service unit:

sudo tee /etc/systemd/system/node_exporter.service > /dev/null <<'EOF'
[Unit]
Description=Prometheus Node Exporter
Wants=network-online.target
After=network-online.target

[Service]
User=node_exporter
Group=node_exporter
Type=simple
ExecStart=/usr/local/bin/node_exporter --web.listen-address=127.0.0.1:9100
Restart=on-failure
RestartSec=5

[Install]
WantedBy=multi-user.target
EOF

Start the service:

sudo systemctl daemon-reload
sudo systemctl enable --now node_exporter

Check its metrics and listener:

systemctl is-active node_exporter
curl -fsS http://127.0.0.1:9100/metrics | head
ss -lntp | grep ':9100'

Verify: Node Exporter should be active, its /metrics endpoint should return Prometheus-format metrics, and port 9100 should be bound only to localhost.

Step 8 — Verify Prometheus is scraping both targets

Wait for at least one scrape interval:

sleep 20

Inspect active targets:

curl -fsS http://127.0.0.1:9090/api/v1/targets | \
  jq -r '.data.activeTargets[] | [.labels.job, .health, .lastError] | @tsv'

Expected health values:

prometheus    up
node_exporter up

Confirm Prometheus has actual host metrics:

curl -fsSG http://127.0.0.1:9090/api/v1/query \
  --data-urlencode 'query=node_uname_info' | \
  jq -r '.data.result | length'

The result should be greater than 0.

Verify: both scrape targets should report up and a Node Exporter query should return at least one result.

Step 9 — Install Grafana from the official stable APT repository

Install the repository prerequisites:

sudo apt-get install -y apt-transport-https wget gnupg

Add the Grafana Labs signing key:

sudo mkdir -p /etc/apt/keyrings
sudo wget -O /etc/apt/keyrings/grafana.asc https://apt.grafana.com/gpg-full.key
sudo chmod 644 /etc/apt/keyrings/grafana.asc

Add the stable repository:

echo "deb [signed-by=/etc/apt/keyrings/grafana.asc] https://apt.grafana.com stable main" | \
  sudo tee /etc/apt/sources.list.d/grafana.list

Install Grafana OSS:

sudo apt-get update
sudo apt-get install -y grafana

Keep Grafana private by binding it to loopback:

sudo sed -i 's/^;\?http_addr =.*/http_addr = 127.0.0.1/' /etc/grafana/grafana.ini

Enable and start Grafana:

sudo systemctl enable --now grafana-server

Check its health and listener:

systemctl is-active grafana-server
curl -fsS http://127.0.0.1:3000/api/health | jq
ss -lntp | grep ':3000'

Verify: Grafana should be active, its health endpoint should respond, and port 3000 should be bound only to 127.0.0.1.

Step 10 — Review UFW safely without risking SSH lockout

Because all three monitoring services are already loopback-only, you do not need public firewall rules for 3000, 9090, or 9100.

Inspect UFW before changing it:

sudo ufw status verbose

Confirm the actual SSH listening port:

sudo sshd -T | awk '/^port / {print $2}'

If UFW is already active, verify the existing SSH rule is correct and confirm no monitoring-port allow rules are present:

sudo ufw status numbered

If UFW is inactive and you want to enable it, allow the actual SSH path first. For standard SSH with the OpenSSH profile:

sudo ufw allow OpenSSH

For a custom SSH port, allow that port instead, for example:

sudo ufw allow 2222/tcp

Keep your current SSH session open and create a second SSH session to verify access. Only after the second session succeeds should you enable UFW:

sudo ufw enable
sudo ufw status numbered

Do not add public allow rules for ports 3000, 9090, or 9100.

Verify: SSH should remain reachable after the firewall change and the monitoring ports should still have no public UFW allow rules.

Step 11 — Open Grafana through an SSH tunnel

From your workstation, create a local tunnel:

ssh -L 3000:127.0.0.1:3000 your-user@your-server-ip

Keep the SSH session open and browse to:

http://127.0.0.1:3000

Grafana's documented first-login defaults are:

Username: admin
Password: admin

Change the administrator password when prompted.

The screenshot is preserved from the original Raff-tested workflow. Labels or minor visual details may differ in newer stable Grafana releases, but the first-login flow remains the same.

From the server, confirm all monitoring listeners are private:

ss -lntp | grep -E ':3000|:9090|:9100'

Verify: Grafana should open through the SSH tunnel, and all three monitoring listeners should show 127.0.0.1.

Step 12 — Connect Grafana to Prometheus

In Grafana, open:

Connections → Data sources → Add data source → Prometheus

Use this Prometheus server URL:

http://127.0.0.1:9090

Click Save & test.

The screenshot is retained from the original tested setup; navigation labels can move between Grafana releases.

Verify the same Prometheus API directly from Ubuntu:

curl -fsSG http://127.0.0.1:9090/api/v1/query \
  --data-urlencode 'query=up' | jq -r '.status'

Expected result:

success

Verify: Grafana should accept the data source and the local Prometheus query should succeed.

Step 13 — Import a Node Exporter dashboard

In Grafana, open:

Dashboards → New → Import

The original Raff-tested workflow used Grafana.com dashboard ID:

1860

Select your Prometheus data source and import the dashboard.

Dashboard 1860 is a community dashboard rather than part of Prometheus itself. If it changes or becomes unavailable, the monitoring stack is still valid. Create a simple Grafana panel with a direct PromQL query such as:

100 - (avg by(instance) (rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100)

Verify: either the imported dashboard or a manually created panel should return Node Exporter data from Prometheus.

Step 14 — Verify Prometheus and Grafana end to end

Open the Node Exporter dashboard through the SSH tunnel, use a recent time range such as Last 15 minutes, and refresh it.

Run the final server checks:

systemctl is-active prometheus
systemctl is-active node_exporter
systemctl is-active grafana-server

prometheus --version | head -n 1
node_exporter --version | head -n 1

curl -fsS http://127.0.0.1:9090/-/ready
curl -fsS http://127.0.0.1:9100/metrics >/dev/null
curl -fsS http://127.0.0.1:3000/api/health | jq

curl -fsS http://127.0.0.1:9090/api/v1/targets | \
  jq -r '.data.activeTargets[] | [.labels.job, .health, .lastError] | @tsv'

curl -fsSG http://127.0.0.1:9090/api/v1/query \
  --data-urlencode 'query=node_uname_info' | \
  jq -r '.data.result | length'

ss -lntp | grep -E ':3000|:9090|:9100'
sudo ufw status numbered

In Grafana, confirm that:

• You can sign in through the SSH tunnel.
• The Prometheus data source passes its connection test.
• A Node Exporter dashboard or manual panel displays current host metrics.
• The dashboard continues to update as new samples are scraped.

End-to-end verification is complete when Prometheus 3.13.2, Node Exporter 1.12.1, and Grafana are active; both Prometheus targets are up; Grafana can query Prometheus; live host metrics appear in a dashboard; and ports 3000, 9090, and 9100 remain loopback-only.

Monitor additional VMs over private network paths

The localhost design is intentionally limited to one server. To monitor additional Raff VMs, install Node Exporter on those target machines and make Prometheus reach them over a controlled private path such as a Raff VPC.

Do not simply bind Node Exporter to 0.0.0.0:9100 and expose it publicly. Decide which interface should listen, restrict network access to the Prometheus server, and add TLS or authentication when the threat model requires it.

For multiple production targets, also plan service discovery, alerting, retention, and Prometheus availability rather than treating this single-node tutorial as a complete observability architecture.

Backup, recovery, and update planning

Prometheus configuration is stored under:

/etc/prometheus

Prometheus time-series data is stored under:

/var/lib/prometheus

Grafana configuration and local state commonly live under:

/etc/grafana
/var/lib/grafana

Preserve the Prometheus configuration and any Grafana dashboards, provisioning files, and local database state you need to rebuild the monitoring plane. Whether the full Prometheus TSDB must also be recoverable depends on your incident-history and compliance requirements.

Raff Data Protection can provide infrastructure-level recovery for the VM, but snapshots do not replace a deliberate application recovery plan. If Prometheus history matters, define what data must survive and test the recovery process you choose.

Before updating Prometheus or Node Exporter, review their release notes, update the pinned version and checksum together, restart the service, and rerun the final verification. Grafana installed through its stable APT repository follows normal package-maintenance updates.

Troubleshooting

Prometheus does not start

Validate the configuration and inspect the service journal:

promtool check config /etc/prometheus/prometheus.yml
sudo journalctl -u prometheus -n 100 --no-pager

Check file access:

sudo -u prometheus test -r /etc/prometheus/prometheus.yml && echo readable
sudo -u prometheus test -w /var/lib/prometheus && echo writable

Node Exporter is down in Prometheus

Check Node Exporter directly:

systemctl is-active node_exporter
curl -fsS http://127.0.0.1:9100/metrics | head

Then inspect Prometheus target errors:

curl -fsS http://127.0.0.1:9090/api/v1/targets | \
  jq -r '.data.activeTargets[] | [.labels.job, .health, .lastError] | @tsv'

Grafana does not open through the SSH tunnel

Check the local Grafana listener on the server:

systemctl is-active grafana-server
curl -fsS http://127.0.0.1:3000/api/health | jq
ss -lntp | grep ':3000'

Recreate the workstation tunnel:

ssh -L 3000:127.0.0.1:3000 your-user@your-server-ip

Then browse to http://127.0.0.1:3000.

Grafana cannot query Prometheus

Check Prometheus readiness and query the API from the same host:

curl -fsS http://127.0.0.1:9090/-/ready
curl -fsSG http://127.0.0.1:9090/api/v1/query \
  --data-urlencode 'query=up' | jq

For this same-VM deployment, the Grafana data source URL should remain http://127.0.0.1:9090.

The dashboard opens but panels show no data

Confirm that Node Exporter samples exist:

curl -fsSG http://127.0.0.1:9090/api/v1/query \
  --data-urlencode 'query=node_uname_info' | \
  jq -r '.data.result | length'

A result greater than 0 proves that Prometheus has Node Exporter data. Then verify the Grafana panel uses the intended Prometheus data source and a time range that includes recent samples.

Prometheus disk usage grows too quickly

Check the TSDB and free disk space:

sudo du -sh /var/lib/prometheus
df -h /

Scrape frequency, target count, metric cardinality, and retention all affect disk usage. Do not reduce retention only to silence a disk alert; first decide how much monitoring history your incident and operations process actually requires.

Enabling UFW could disconnect SSH

Do not enable UFW from a single remote session until you have confirmed the actual SSH port and added the matching allow rule. Keep the current session open, verify a second SSH connection, and use a provider console or other recovery path when available.

Cleanup and rollback

For a reversible shutdown, stop the monitoring services without deleting data:

sudo systemctl stop grafana-server prometheus node_exporter

Restart them later with:

sudo systemctl start node_exporter prometheus grafana-server

For permanent decommissioning, back up any Grafana state and Prometheus data you need before removing packages, binaries, unit files, /etc/prometheus, /var/lib/prometheus, /etc/grafana, or /var/lib/grafana.

Do not remove unrelated SSH or firewall configuration as part of monitoring cleanup.

Conclusion

You now have a current Prometheus and Grafana monitoring stack for Ubuntu 24.04. Prometheus 3.13.2 runs on the supported LTS line, Node Exporter supplies host metrics, Grafana queries Prometheus locally, and all three monitoring web interfaces stay bound to localhost.

The workflow also avoids blind firewall activation, keeps the existing SSH-tunnel security model, and leaves a clear path to multi-VM monitoring over private networking when the single-host pattern is no longer enough.

Sources

• Prometheus documentation — downloads, LTS release cycle, configuration, and Node Exporter guide
• Prometheus GitHub releases — Prometheus 3.13.2 and Node Exporter 1.12.1 checksums and release status
• Grafana documentation — Debian/Ubuntu APT installation, server configuration, and first sign-in
• Guidance re-verified: 2026-09-07
