Portainer provides a web interface for managing Docker containers, images, networks, volumes, and Compose stacks. In this tutorial, you will install Portainer Community Edition on a Raff Linux VM running Ubuntu 24.04, keep the management UI off the public Docker port, place it behind Nginx and Let's Encrypt, create the first administrator, manage the local Docker environment, deploy a test stack, back up Portainer's configuration, and verify the deployment end to end.
Portainer has privileged access to the Docker daemon when you mount /var/run/docker.sock, so the Portainer administrator effectively has control over the Docker host. Treat the dashboard as an administrative interface, not a public application. This guide therefore binds Portainer's HTTPS port to localhost and publishes it through an authenticated administrator-facing hostname such as portainer.example.com instead of opening port 9443 directly to the internet.
For production workloads, Portainer recommends its LTS release stream. As of October 27, 2026, Portainer 2.45.3 LTS is the latest published LTS maintenance release. The 2.45.x series includes the earlier Docker API authorization fix. This tutorial uses the moving lts image stream, so verify the running version and review the official release notes before updating. No new 2.45.3 end-to-end VM retest is claimed. You need Docker with Compose v2, Nginx, a domain pointed to the VM, and a non-root user with sudo privileges.
Step 1 — Confirm Ubuntu, Docker, and DNS
Check the operating system:
cat /etc/os-release
Check Docker and Compose:
docker --version docker compose version
Check that the management hostname resolves to the VM:
dig +short A portainer.example.com
If Docker is not installed, follow How to Install Docker on Ubuntu 24.04. Use Docker Engine installed through Docker's supported Linux installation path rather than the Ubuntu Snap package; Portainer's current Docker-on-Linux guidance warns that Docker installed via Snap can cause compatibility issues. If Nginx is missing, install it before configuring the reverse proxy.
Verify: Ubuntu should report 24.04, Docker Compose v2 should respond, the DNS A record should return the VM's public IPv4 address, and your Docker installation should not be the Snap-packaged variant.
Step 2 — Create Persistent Portainer Storage
Create the Docker volume that stores Portainer's configuration database and settings:
docker volume create portainer_data
Inspect it:
docker volume inspect portainer_data
This volume is separate from the Portainer container. Removing and recreating the container does not delete the configuration unless you also remove the volume.
Verify: docker volume inspect portainer_data should return the volume metadata without an error.
Step 3 — Deploy Portainer CE on the LTS Release Stream
Run Portainer with its management HTTPS port bound only to localhost:
docker run -d \ --name portainer \ --restart=always \ -p 127.0.0.1:9443:9443 \ -v /var/run/docker.sock:/var/run/docker.sock \ -v portainer_data:/data \ portainer/portainer-ce:lts
Portainer's official Docker installation uses port 9443 for the HTTPS UI. Port 8000 is optional and is only required when you use Edge Agent tunnel features, so this single-host deployment does not publish it.
The Docker socket mount gives Portainer broad control over the Docker daemon. Anyone who gains Portainer administrator access can perform actions equivalent to administrative Docker access, so protect this service accordingly.
Check the container:
docker ps --filter name=portainer
Review startup logs:
docker logs --tail=50 portainer
Verify: The container should be running and sudo ss -ltnp | grep 9443 should show 127.0.0.1:9443, not 0.0.0.0:9443.
Step 4 — Verify the Portainer Version Before Continuing
Check the installed Portainer version:
docker exec portainer /portainer --version
Avoid unpatched Portainer builds affected by the 2026 Docker API authorization bypass. The fix was included in 2.45.0 LTS and 2.39.7 LTS; as of October 27, 2026, the latest 2.45 LTS maintenance release is 2.45.3. The moving lts tag should track a supported stream, but verify the actual running version so an old local image is not mistaken for a patched deployment.
If the version is stale, pull the LTS image and recreate Portainer:
docker pull portainer/portainer-ce:lts docker stop portainer docker rm portainer
Then rerun the deployment command from Step 3.
Verify: The reported version should be a supported, patched LTS release. As of October 27, 2026, the current published 2.45 LTS maintenance release is 2.45.3.
Step 5 — Configure Nginx as the Public Entry Point
Create an Nginx server block:
sudo nano /etc/nginx/sites-available/portainer.example.com
Add:
server { listen 80; listen [::]:80; server_name portainer.example.com; location / { proxy_pass https://127.0.0.1:9443; proxy_http_version 1.1; proxy_set_header Host $host; proxy_set_header X-Real-IP $remote_addr; proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for; proxy_set_header X-Forwarded-Proto $scheme; proxy_set_header Upgrade $http_upgrade; proxy_set_header Connection "upgrade"; proxy_ssl_verify off; proxy_read_timeout 600s; proxy_send_timeout 600s; } }
Portainer generates a self-signed certificate for its internal HTTPS listener by default. Because this upstream connection stays on loopback, Nginx can proxy to it while public users receive the trusted Let's Encrypt certificate configured in the next step. The Upgrade and Connection headers preserve WebSocket-based management paths such as interactive console sessions. proxy_ssl_verify off applies only to the local self-signed upstream connection in this configuration.
Enable the site:
sudo ln -s /etc/nginx/sites-available/portainer.example.com \ /etc/nginx/sites-enabled/portainer.example.com sudo nginx -t sudo systemctl reload nginx
Verify: sudo nginx -t should report successful syntax and curl -I http://portainer.example.com should reach the Nginx virtual host.
Step 6 — Add HTTPS and Keep Portainer's Direct Port Private
If UFW is active, make sure SSH remains allowed before changing firewall rules:
sudo ufw status sudo ufw allow OpenSSH
Allow Nginx traffic:
sudo ufw allow 'Nginx Full'
Do not add a public UFW rule for port 9443 because Docker is already binding it to localhost only. This keeps the direct Portainer backend private, but the Nginx hostname can still be reachable from the public internet. Treat that hostname as a privileged administrative endpoint; for higher-security environments, restrict it with a VPN, trusted-source IP policy, or another deliberate access-control layer.
Install Certbot and request a certificate:
sudo apt install -y certbot python3-certbot-nginx sudo certbot --nginx --redirect -d portainer.example.com
Test certificate renewal:
sudo certbot renew --dry-run
Verify: curl -I https://portainer.example.com should complete over HTTPS, HTTP should redirect to HTTPS, and sudo ss -ltnp | grep 9443 should still show the backend bound to localhost only.
Step 7 — Create the First Administrator Within the Setup Window
Open:
https://portainer.example.com
Create the first administrator. Portainer requires the initial password to be at least 12 characters. Use a unique password stored in a password manager.
Portainer intentionally times out an uninitialized installation if the first administrator is not created within five minutes. If the instance reports that it timed out for security purposes, restart it:
docker stop portainer docker start portainer
Then complete the initial setup promptly.
After the administrator is created, Portainer should automatically detect the local Docker environment. Select Get Started to manage it.
Verify: You should be able to sign in over the public HTTPS hostname and see the local Docker environment without a browser certificate warning.
Step 8 — Inspect the Local Docker Environment Safely
Open the local environment in Portainer and review:
- Containers
- Images
- Networks
- Volumes
- Stacks
Use the UI for routine inspection and lifecycle actions, but remember that Portainer is an administrative control plane. Avoid granting dashboard access merely as a substitute for application-level access.
From the command line, compare what Docker sees:
docker ps -a docker volume ls docker network ls
The resources shown by these commands should correspond with the Portainer dashboard.
Verify: An existing Docker container should appear in both docker ps -a and the Portainer Containers view with matching state.
Step 9 — Deploy and Remove a Test Docker Compose Stack
In Portainer, open Stacks and create a stack named portainer-test. Use the web editor with:
services: web: image: nginx:alpine restart: unless-stopped ports: - "127.0.0.1:8080:80"
Deploy the stack. The test container is deliberately bound to localhost so you do not need to expose another public firewall port just to verify the stack workflow.
Test it from the VM:
curl -I http://127.0.0.1:8080
Then remove the test stack from Portainer when the check is complete.
Confirm cleanup:
sudo ss -ltnp | grep 8080 || echo 'test port removed'
Verify: The local curl should return an Nginx HTTP response before cleanup, and port 8080 should no longer be listening after the test stack is removed.
Step 10 — Back Up the Portainer Configuration
Portainer's built-in backup contains the configuration stored in its /data volume. It does not back up the application containers, Docker volumes, or databases that Portainer manages.
In the Portainer UI, sign in as an administrator and open Settings. In Back up Portainer, download a configuration backup. Password-protect the archive if your operational process supports securely storing the backup password.
For infrastructure recovery, protect Docker application state separately. Depending on your workloads, that can include database-native backups, volume backups, application configuration, and VM-level recovery points. Raff Data Protection can cover the VM recovery layer, while application-aware backups should remain part of the workload's own recovery design.
After downloading the Portainer backup, store it somewhere other than the VM itself. Protect and test the backups of each Docker workload independently of Portainer's own configuration archive.
Verify: Confirm the Portainer backup archive exists off-server and that your separate application backup process covers any persistent Docker workloads you would need to restore.
Step 11 — Update Portainer Without Losing Configuration
Before updating, create a Portainer configuration backup from Step 10. Then pull the supported LTS image:
docker pull portainer/portainer-ce:lts
Stop and remove only the Portainer container:
docker stop portainer docker rm portainer
Recreate it with the same portainer_data volume:
docker run -d \ --name portainer \ --restart=always \ -p 127.0.0.1:9443:9443 \ -v /var/run/docker.sock:/var/run/docker.sock \ -v portainer_data:/data \ portainer/portainer-ce:lts
Check the version and logs:
docker exec portainer /portainer --version docker logs --tail=100 portainer
Your Portainer users and settings remain in portainer_data. Removing the Portainer container does not remove other Docker containers on the host.
Verify: You should be able to log in with the existing administrator account, the local environment should still be present, and the reported Portainer version should match the intended patched LTS release.
Step 12 — Troubleshoot Common Portainer Problems
If the UI returns a proxy error, first confirm Portainer itself is running:
docker ps --filter name=portainer docker logs --tail=100 portainer curl -kI https://127.0.0.1:9443
If the local HTTPS request works but the public hostname fails, test Nginx:
sudo nginx -t sudo tail -n 50 /var/log/nginx/error.log
If Portainer appears to be a fresh installation after an update, confirm the correct data volume is mounted:
docker inspect portainer \ --format '{{range .Mounts}}{{println .Source "->" .Destination}}{{end}}'
You should see a mount ending in -> /data and the Docker socket mount ending in -> /var/run/docker.sock.
If setup timed out before the first administrator was created, restart the container as shown in Step 7.
Verify: The backend request, Nginx configuration, Docker mounts, and Portainer logs should all agree on the failure path before you change the deployment.
Step 13 — Run the Final End-to-End Verification
Check the container and version:
docker ps --filter name=portainer docker exec portainer /portainer --version
Check that 9443 remains private:
sudo ss -ltnp | grep 9443
Check the public HTTPS path:
curl -I https://portainer.example.com
Check recent logs:
docker logs --tail=100 portainer sudo tail -n 50 /var/log/nginx/error.log
Finally, sign in through the browser and confirm the local environment shows the same containers as:
docker ps -a
Verify: Portainer should be running on a patched LTS release, port 9443 should be localhost-only, the public hostname should use trusted HTTPS, the administrator should be able to sign in, and Docker resources should be visible in the local environment.
Step 14 — Remove Portainer Without Accidentally Deleting Other Containers
To remove only the Portainer container:
docker stop portainer docker rm portainer
This does not remove the other application containers that Portainer was managing.
Remove the Nginx site if it is no longer needed:
sudo rm -f /etc/nginx/sites-enabled/portainer.example.com sudo rm -f /etc/nginx/sites-available/portainer.example.com sudo nginx -t sudo systemctl reload nginx
Keep portainer_data if you may reinstall Portainer later. If this is a disposable test and you intentionally want to erase Portainer's users and configuration, first verify your backup and then remove the volume:
docker volume rm portainer_data
If the Let's Encrypt certificate is no longer needed, inspect certificates before deleting anything:
sudo certbot certificates
Then delete only the retired hostname's certificate:
sudo certbot delete --cert-name portainer.example.com
Verify: docker ps -a should show that your unrelated application containers still exist, while the Portainer container is gone. Remove portainer_data only when intentional configuration loss is acceptable.
Conclusion
You now have Portainer CE installed on Ubuntu 24.04 as a Docker management UI with persistent configuration, localhost-only backend exposure, Nginx, trusted HTTPS, a verified LTS release, a working local Docker environment, a tested Compose stack workflow, configuration backup, update instructions, troubleshooting, and cleanup steps.
Portainer can share a Raff Linux VM with other Docker workloads, but size the host for the applications and databases you run, not just for the management dashboard. Compare current Raff pricing for the VM resources you need. Because a Portainer administrator has broad control over the Docker host, follow the Docker Host Security Checklist for Production VMs. For an end-to-end application example, see Gitea with Docker Compose.
